MM4X4 lockup-mate®MX 4JJ1/3

Key Features…

• Fully plug’n play installation – simple DIY installation and is easily removable without trace

• Advanced Digital Control – for fully automatic lockup control, protection, and advanced features

• CANBus interface to ECUs – to determine key operational data like speed, gear, load, RPM, mode (Drive, Manual, 4L) etc.

• Separate lockup strategies for DRIVE and MANUAL

• Lockup in high range (35 KPH+) in 3rd–6th gears – no manual button lockup nor in 2nd and 4L to avoid transmission LIMP modes and potential damage

• Lockup when coasting – for maximum engine braking and direct drive responsiveness

• Load sensitive – for transmission protection and improved drivability

• SafeLock® – for driveline and clutch protection

• Factory-like PWM solenoid control – for maximum performance and to avoid a burnt out solenoid!

• LED/Switch:

–    Lockup Status is easily visible to assist the driver with maximising benefits
–    Also a momentary switch to toggle the kit on and off
–    Slip Alert – advising driver when to downshift to regain full lockup (when in MANUAL mode)
–    Auto-Dim – linked to the headlight being ON, with manual override for daytime headlight use

–    Warmup – kit automatically deactivates while waiting for the transmission to warmup and pulses the LED to let the driver know

• Self-Test Diagnostics Mode – to confirm operation after installation

• Engine Light (CEL) reset feature – to self-recover from an installation related error code

• OBD2 interface – to allow lockup kit and extra vehicle parameters to be displayed on your OBD2 gauge
